Precise Double Sided PCB with Immersion Gold Surface 100% E test Green Solder Resist

Precise Double Sided PCB with Immersion Gold Surface 100% E test Green Solder Resist

Contact Us
Request A Quote
Product Details
100% E-test
Solder Resist Color:
Surface Treatment:
Immersion Gold
Pcb Thickness:
Silkscreen Color:
DHL UPS EMS TNT FedEx,Express Courier,Sea Transport
Min Hole Dia:
0.075 Mm
Payment & Shipping Terms
Contact Us
Product Description

Product Description:

The Double-Sided PCB, boasting a conductor space of just 3 mil, is an advanced solution for a wide range of electronics applications. This Two-Sided Circuit Board is meticulously designed to cater to high-precision requirements, ensuring that even the most intricate of circuits can be accommodated with ease. As technology progresses, the demand for overlength PCBs that can support complex circuits without compromising on performance has grown. Our product is a testament to this evolution, offering unmatched reliability and efficiency.

One of the most notable features of this Double-Sided Printed Board is its solder resist color. The vibrant green hue not only provides a clear contrast for easy inspection of solder joints and pathways but also acts as a protective layer against oxidation and corrosion. This feature is especially important for boards that are exposed to harsh environments or are in use for extended periods. The green solder resist is a mark of quality and durability, safeguarding the circuitry and ensuring the longevity of the PCB.

Surface treatment is a critical factor in the performance of PCBs, and our Double-Sided PCB is no exception. It comes with an Immersion Gold surface treatment that offers excellent conductivity and resistance to wear. This treatment is known for its ability to provide a flat surface which is ideal for fine-pitch components or for applications requiring repeated assembly and disassembly. Immersion Gold treatment also enhances the electrical performance of the PCB, making it a preferred choice for high-frequency or high-speed applications.

The surface finish of a PCB can greatly influence its solderability and protection against oxidation. Our product offers a range of surface finishes, including HASL (Hot Air Solder Leveling), ENIG (Electroless Nickel Immersion Gold), Immersion Tin, Immersion Silver, Gold Finger, and OSP (Organic Solderability Preservative). These options provide versatility to meet different assembly and performance requirements. HASL is a widely used surface finish that provides a good solderable surface and is cost-effective. ENIG offers superior surface planarity and is excellent for fine-pitch technology, while Immersion Tin and Immersion Silver are ideal for flat surface requirements. Gold Finger finish is typically used on the connecting edges of PCBs for repeated insertion, and OSP is a surface finish that is great for those looking for a lead-free solution.

With a standard PCB thickness of 1.6mm, this Double-Sided PCB strikes the perfect balance between strength and flexibility. This thickness is the industry standard and is preferred for its mechanical robustness and ease of handling during the assembly process. It is thick enough to provide a solid foundation for the components while being thin enough to allow for efficient thermal management and electrical performance. Whether used in consumer electronics, automotive applications, or industrial equipment, the 1.6mm thickness ensures that the board can withstand the rigors of everyday use without sacrificing functionality.

In summary, the Double-Sided PCB with a conductor space of 3 mil is a superior product that combines advanced features with robust construction. The green solder resist color, various surface treatment options, and a range of surface finishes make it adaptable to various applications and environments. The 1.6mm thickness ensures durability and performance, making it a go-to choice for both standard and overlength PCBs requirements. Whether for complex multi-component assemblies or for simple circuits, this Two-Sided Circuit Board is engineered to deliver consistent, high-quality results that our customers can rely on.



  • Product Name: Double Sided PCB
  • Feature: 100% E-test
  • Silkscreen Color: White, Black, Yellow
  • Layers: Double
  • Surface Treatment: Immersion Gold
  • Surface Finish: HASL, ENIG, Immersion Tin, Immersion Silver, Gold Finger, OSP
  • Also known as: Dual-Sided Printed Wiring Board
  • Type: Dual-Sided PCB
  • Application: Dual-Sided PCB for various electronics

Technical Parameters:

Parameter Details
Layers Double
Surface Treatment Immersion Gold
Keyword Two Layer PCB
Conductor Space 3 Mil
Silkscreen White, Black, Yellow
Raw Material FR-4
Solder Resist Color Green
Surface Finish HASL, ENIG, Immersion Tin, Immersion Silver, Gold Finger, OSP
Color Green, Blue, Yellow
Silkscreen Color White, Black, Yellow


The Double Sided PCB, also known as Dual-Sided PCB, has become an essential component in various electronic applications due to its versatility and efficiency in connecting electronic components. With a standard PCB thickness of 1.6mm, it ensures durability and firmness in various assembly scenarios. The silkscreen color options available for this PCB include white, black, and yellow, which offer not only clear marking for component placement but also customization options to match different design aesthetics and requirements.

One of the standout features of the 1.5m double-sided PCB is its 100% E-test guarantee, which ensures that each PCB is rigorously tested for electrical performance before being dispatched. This level of quality control is crucial for applications where reliability and safety are paramount. The raw material used in the construction of these Double-Plated PCBs is FR-4, a well-known and widely used flame-retardant substrate that provides excellent mechanical strength, thermal stability, and electrical insulation.

Given its robust build and reliable performance, the Double Sided PCB finds its application in a host of scenarios. It's commonly used in the manufacturing of industrial controls where the double-sided design allows for a complex yet compact circuitry that can handle multiple functions within a small footprint. This type of PCB is also prevalent in automotive electronics, where the durability of the FR-4 material and the rigorous E-testing ensure long-term reliability in the harsh conditions experienced by vehicle electronics.

Consumer electronics is another arena where these dual-layer PCBs shine. From smartphones to home appliances, the 1.5m double-sided PCB is instrumental in providing the necessary connectivity while maintaining a slim profile, which is essential for modern, sleek product designs. Additionally, in the realm of medical devices, where precision and reliability are non-negotiable, the Double-Plated PCBs are highly valued for their consistent performance and adherence to stringent quality standards.

In summary, the Double Sided PCB with its 1.6mm thickness, variety of silkscreen colors, and the guarantee of a 100% E-test, is a versatile product suitable for numerous applications. From automotive to consumer electronics, industrial controls, and medical equipment, the quality and reliability of these PCBs make them an indispensable component in today's electronic product landscape.



Our Double Sided PCB, also known as a Twin Layer PCB or Two-Sided Circuit Board, offers a range of product customization services to meet your specific requirements. The standard Solder Resist Color for our Bi-Layer PCB is Green, ensuring a robust and reliable finish. We provide options for Silkscreen Color, available in White, Black, and Yellow, allowing for clear and legible markings on your PCBs.

To accommodate intricate designs, we offer a Conductor Space of 3 Mil for precision and high-density component placement. Our Double Sided PCBs come with various Surface Finish options, including HASL, ENIG, Immersion Tin, Immersion Silver, Gold Finger, and OSP, each offering unique benefits to suit different applications.

In addition to the standard Green Solder Resist Color, we also offer customization in other colors such as Blue and Yellow, giving you the freedom to personalize the appearance of your Twin Layer PCBs for better aesthetics or identification purposes.


Support and Services:

Our Double Sided PCB product is backed by comprehensive technical support and services to ensure your complete satisfaction and success with our product. Our team of experienced engineers and technical support specialists are available to assist you with any questions or issues you may encounter during the use of our Double Sided PCBs.

We provide a range of services including but not limited to:

  • Design assistance to help optimize your PCB layout for manufacturing efficiency and reliability.

  • Detailed documentation and guides that cover specifications, material data, and handling procedures for our Double Sided PCBs.

  • Technical troubleshooting to address and resolve any performance issues that may arise during the use of our product.

  • Recommendations on best practices for PCB assembly, soldering, and testing to ensure the longevity and durability of your Double Sided PCBs.

  • Assistance with any firmware or software integration that may be required for the operation of your Double Sided PCB within your product or system.

We are committed to providing prompt and effective support to minimize any downtime and to ensure your project deadlines are met. Whether you're in the design phase, production stage, or post-production support, our team is here to provide the necessary assistance every step of the way.

Please note that our product support does not include physical repairs or replacements of damaged PCBs due to user error or mishandling. However, we can offer guidance on how to prevent such issues in the future and can assist in assessing the feasibility of repair options.

For further assistance, please refer to our online resources or reach out to our technical support team at your convenience. We are dedicated to ensuring that your experience with our Double Sided PCB product is positive and that the product meets your technical requirements and expectations.
