Lead Free HASL Surface Finishing Flex Rigid PCB Superior Durability and Performance

Product Description:

A Bendable Printed Circuit Board, also known as a Rigid Flex PCB, is a versatile electronic component that combines the benefits of both rigid and flexible PCBs. This innovative technology allows for increased design flexibility and reliability in various applications. One of the standout products in this category is the 16-layer Rigid Flex PCB with a green solder mask color.

The solder mask color of green adds a visually appealing touch to the Rigid Flex PCB while providing essential protection to the circuitry. The green color is a standard choice in the industry and is widely recognized for its durability and reliability.

When it comes to stiffener options, this Rigid Flex PCB offers a choice of three materials: Polyimide, FR4, and Stainless Steel. Each material has its own unique properties that cater to different project requirements. Polyimide is known for its excellent thermal resistance and flexibility, making it ideal for applications where bending or flexing is required. FR4, on the other hand, offers high mechanical strength and is commonly used in rigid sections of the board. Stainless Steel stiffeners provide unparalleled rigidity and support, perfect for demanding applications.

With a finished copper weight of 1oz, this Rigid Flex PCB ensures optimal conductivity and signal integrity. The 1oz copper thickness strikes a balance between performance and cost-effectiveness, making it suitable for a wide range of electronic devices and systems.

Featuring 16 layers, this Rigid Flex PCB offers ample space for complex circuit designs and high-density components. The multiple layers allow for efficient routing of signals and power, enhancing the overall performance of the PCB.

Furthermore, this Rigid Flex PCB has a maximum layer count of 52L, providing even greater design possibilities for advanced electronic applications. The high layer count allows for intricate and compact designs, making it a top choice for projects that require a high level of integration.

In summary, the 16-layer Rigid Flex PCB with a green solder mask color, Polyimide, FR4, and Stainless Steel stiffener options, 1oz finished copper weight, and a maximum layer count of 52L is a versatile and reliable solution for a wide range of electronic design challenges. Whether you are working on a complex electronic system or a compact portable device, this Rigid Flex PCB offers the flexibility and performance you need to bring your ideas to life.

Features:

• Product Name: Rigid Flex PCB
• Stiffener Options: Polyimide, FR4, Stainless Steel
• Min. Line Width/Spacing: 0.075mm/0.075mm
• Min Line Space: 8mil
• Processing: Assembly
• Layer Count: 16 Layers

Technical Parameters:

Applications:

The Bendable Rigid Printed Wiring Board, also known as Rigid Flex PCB, is a versatile and innovative product that is suitable for a wide range of application occasions and scenarios. With finished copper of 1OZ, a minimum line space of 8mil, and a vibrant green solder mask color, this product is ideal for various industries and projects.

One of the key features of the Bendable Rigid Printed Wiring Board is its flexibility, allowing it to be used in applications where traditional rigid PCBs would not be suitable. This makes it a great choice for products that require a combination of flexibility and rigidity.

Whether you are working on consumer electronics, medical devices, automotive systems, or industrial equipment, the Bendable Rigid Printed Wiring Board can meet your needs. Its ability to support components such as SMDs, BGAs, DIPs, and more, makes it a versatile option for a wide range of projects.

When it comes to product development, having the right files is crucial. The Bendable Rigid Printed Wiring Board requires Gerber or PCB files for manufacturing, ensuring smooth production processes and accurate results.

From wearable technology to aerospace applications, the Bendable Rigid Printed Wiring Board can be used in various scenarios where space is limited, and flexibility is required. Its innovative design and durable construction make it a reliable choice for demanding environments.

In conclusion, the Bendable Rigid Printed Wiring Board is a cutting-edge product that offers flexibility, reliability, and versatility. Whether you are designing a new electronic device or upgrading an existing system, this product can provide the performance and durability you need.

Customization:

Our Product Customization Services for the Rigid Flex PCB include:

Thickness: 0.6mm

Processing: Assembly

Layer Count: 16 Layers

Min. Line Width/Spacing: 0.075mm/0.075mm

Finished Copper: 1OZ

For the Rigid Flex Printed Wiring Board, Bendable Printed Circuit Board, and Flex-Rigid Printed Circuit Board.

Support and Services:

Rigid Flex PCBs combine the features of rigid boards and flexible circuits into a single package, offering unique design possibilities for various applications. Our product technical support team is dedicated to providing assistance with design guidelines, material selection, manufacturing processes, and troubleshooting to ensure optimal performance of your Rigid Flex PCBs.

Our service offerings include design consultation, prototyping, testing, and quality assurance to help you bring your Rigid Flex PCB projects to fruition efficiently and effectively. Whether you require customization, modifications, or technical advice, our team of experts is here to support your needs and provide comprehensive services tailored to your requirements.
