The Dual-Sided PCB, also commonly referred to as Double-Sided PCB, is a significant advancement in the circuit board industry that has paved the way for more complex and versatile electronics. This product is specifically designed to cater to sophisticated electronic applications that require a higher level of circuitry integration without compromising the size and weight of the devices. Our 1.2m double-sided PCBs are crafted with precision and are ideal for a wide range of applications including industrial controls, automotive systems, and consumer electronics.
One of the most notable features of our Double-Sided PCBs is the variety of silkscreen colors available to our clients. We offer silkscreen in White, Black, and Yellow options, providing flexibility in design and ensuring clear legibility of the printed information on the board. The silkscreen layer is essential for indicating the positions of various components on the PCB, making the assembly process more efficient and reducing the likelihood of errors.
Equally important in the manufacturing of our Dual-Sided PCBs is the solder resist color. We utilize a standard Green solder resist which serves as a protective layer over the copper traces. This solder mask helps to prevent accidental solder bridging during assembly, which could otherwise lead to short circuits. The green color also provides a strong contrast against the silkscreen, making it easier for technicians to work on the PCBs during the assembly and testing phases.
Our Dual-Sided PCBs are engineered with a copper weight range of 1-6oz, allowing for flexibility and customization based on the current-carrying requirements of the electronic device. A higher copper weight can be advantageous for applications that demand a higher power or where thermal management is critical. The versatility in copper weight selection ensures that each Double-Sided PCB can be tailored to the specific needs of the application, resulting in optimal performance and reliability.
The robustness and reliability of our 1.2m double-sided PCBs are matched by our commitment to providing convenient and efficient shipping options. We have partnered with leading logistics providers including DHL, UPS, EMS, TNT, FedEx, and other Express Couriers to ensure that our products are delivered promptly and securely to our customers worldwide. For larger orders or specific delivery needs, Sea Transport is also available, offering a cost-effective solution for bulk shipments.
In summary, our Dual-Sided PCBs stand out for their customizable features such as the choice of silkscreen colors (White, Black, Yellow), the standard green solder resist, and the flexible copper weight options ranging from 1-6oz. Manufactured with precision and designed to meet the rigorous demands of modern electronics, these PCBs are a reliable foundation for any electronic application. Coupled with our extensive shipping options that cater to both speed and budget requirements, our Double-Sided PCBs represent a pinnacle of quality and service in the circuit board industry. For clients seeking excellence in electronic components, our 1.2m double-sided PCBs offer the perfect balance of advanced technology, customization, and convenience.
| Parameter | Details |
|---|---|
| Silkscreen Color | White, Black, Yellow |
| Surface Treatment | Immersion Gold |
| Solder Resist Color | Green |
| Layers | Double |
| Conductor Space | 3 Mil |
| Min Hole Dia | 0.075 Mm |
| Copper Weight | 1-6oz |
| Silkscreen | White, Black, Yellow |
| Shipping | DHL, UPS, EMS, TNT, FedEx, Express Courier, Sea Transport |
| Color | Green, Blue, Yellow |
The 1.2m double-sided PCB is an exceptional product designed to cater to various applications requiring overlength PCBs. These Extra long double-sided PCBs are ideal for use in industries where space constraints are a concern, and extensive circuitry is needed within a compact form factor. The double-sided nature of these PCBs allows for a more complex and dense circuit design, making them suitable for sophisticated electronic devices.
With a conductor space of just 3 Mil, these Two Layer PCBs offer high-density circuit placement, ensuring that electronic devices can achieve superior performance while maintaining a slim profile. The color options available for these PCBs, including green, blue, and yellow, provide users with the flexibility to choose a design that best fits the aesthetic and visibility requirements of their projects. The silkscreen color options of white, black, and yellow further enhance the customization capabilities of these PCBs, allowing for clear and distinct marking of components and test points.
These double-sided PCBs are widely used in industry applications such as telecommunications, where large-scale, high-speed, and reliable connections are critical. They are also found in medical devices, where precision and reliability are paramount, and space is often limited. In the field of LED lighting, the 1.2m double-sided PCB allows for the creation of extended lighting arrays, providing uniform and efficient illumination over large areas.
Shipping these overlength PCBs is made seamless and reliable with a variety of shipping options, including DHL, UPS, EMS, TNT, FedEx, Express Courier, and Sea Transport. These shipping services ensure that the PCBs can be delivered promptly and safely to any location worldwide, catering to the just-in-time manufacturing needs of various industries. Whether you're prototyping or in full-scale production, these shipping options provide the flexibility to meet strict project timelines and supply chain requirements.
In summary, the 1.2m double-sided PCB product is versatile, reliable, and suitable for a vast array of applications where overlength PCBs are a necessity. Its high-quality construction, coupled with the convenience of multiple shipping options and customizable features, makes it an excellent choice for designers and engineers looking to push the boundaries of electronic device innovation.
Our Double Sided PCBs are expertly crafted with two layers of connectivity for complex circuits, using high-quality FR-4 raw material to ensure durability and performance. We offer a variety of silkscreen color options, including White, Black, and Yellow, to match your design preferences and enhance the readability of your PCB.
We specialize in overlength PCBs, accommodating sizes up to 1.5m for your double-sided PCB needs. Whether you require a standard 1.2m double-sided PCB or a custom size, our product customization services cater to your specific requirements. With a standard PCB thickness of 1.6mm, we maintain a balance between strength and flexibility.
Our shipping options are comprehensive, providing you with a choice of DHL, UPS, EMS, TNT, FedEx, Express Courier, or Sea Transport for reliable and timely delivery of your PCBs regardless of your location. Choose our Double Sided PCB product for a perfect blend of quality, customization, and convenience.
Our Double Sided PCB products come with comprehensive technical support and services to ensure your complete satisfaction. With a focus on quality and customer service, we provide the following support options:
Technical Documentation: Detailed documentation including specifications, design guidelines, and material data sheets are available to support your product integration and usage.
Design Assistance: Our team of experienced engineers can assist you with PCB design considerations, helping to optimize your circuit layout for performance and manufacturability.
Product Customization: We offer customization services to meet your specific requirements. Whether it's a unique shape, size, or layer stack-up, we can tailor our Double Sided PCBs to suit your needs.
Quality Assurance: All of our PCBs undergo rigorous testing and quality control measures to ensure they meet the highest industry standards. We stand behind our products with a commitment to quality.
Troubleshooting Assistance: If you encounter any issues with your PCB, our support team is here to help diagnose and resolve problems quickly and efficiently.
After-Sales Support: We are dedicated to providing ongoing support for our products. Our support team is available to assist with any post-purchase inquiries or concerns you may have.
