Black Solder Mask Ceramic PCB Board Manufacturing One Stop Service

Black Solder Mask Ceramic PCB Board Manufacturing One Stop Service

Ceramic PCB Board One Stop Service

One Stop Service ceramic substrate pcb

Black Solder Mask Ceramic PCB Board

Contact Us
Request A Quote
Product Details
Thermal Conductivity:
170 W/mK
Solder Mask Colour:
Black
Product Type:
PCB&PCBAOEM,DFM
Service:
One-stop Service / OEM,DFM
Dielectric Constant:
6.0-10.0
Min Line Width/Spacing:
0.1mm
Surface Finished:
Immersion Gold,nickel-palladium GLOD
Pcb Size:
22mm*19mm
Payment & Shipping Terms
RELATED PRODUCTS
Contact Us
Contact Now
Product Description

Ceramic PCB Board with Thermal Conductivity Black Solder Mask 0.1mm Min Line Width/Spacing

Product Description:

Introducing the pinnacle of printed circuit board (PCB) technology, the Immersion Gold Ceramic PCB Board, a state-of-the-art solution designed to meet the highest demands of thermal conductivity and electrical performance. This premium PCB is meticulously crafted using cutting-edge ceramic glass composite materials, ensuring unparalleled durability, stability, and efficiency for a wide array of applications.

At the heart of this exceptional PCB lies its robust ceramic substrate. Made from high-grade aluminum nitride (ALN), the ALN Ceramic PCBs offer an impressive thermal conductivity that far surpasses traditional FR4 boards. This makes them an ideal choice for high-power circuits, LED lighting systems, and other applications that generate a considerable amount of heat. The superior thermal properties of ALN help in effectively dissipating heat, thereby enhancing the longevity and reliability of the components mounted on the PCB.

One of the defining features of the Immersion Gold Ceramic PCB Board is its impressive Min Line Width/Spacing of just 0.1mm. This fine level of detail allows for more complex and intricate circuit designs, ensuring that even the most space-constrained applications can be accommodated without compromising performance. This precision, combined with the board's ability to operate over an extensive temperature range of -50°C to 150°C, makes it a versatile solution that can withstand harsh environmental conditions and high-temperature operations.

Flexibility in design is further emphasized with the board's accommodating size range of 2mm to 200mm. Whether it's for compact electronic gadgets or larger industrial equipment, the Ceramic PCB Board can be tailored to fit specific requirements, providing a perfect platform for innovation across various sectors, including aerospace, automotive, and medical devices.

The surface finish is another aspect where the Immersion Gold Ceramic PCB Board truly shines. The application of Immersion Gold over a nickel-palladium GLOD layer ensures not only a smooth and flat surface for mounting components but also offers excellent oxidation resistance. This surface finish enhances the board's electrical performance by providing a reliable interface for signal transmission and reducing contact resistance. Additionally, the nickel-palladium underlayer adds an extra degree of durability, protecting the copper circuits from corrosion and wear over time.

For those looking to integrate a Ceramic Board with Copper Clad Laminate into their projects, this PCB is an impeccable choice. The copper cladding is of the highest quality, offering exceptional electrical conductivity and helping to further improve the thermal performance of the board. By using a ceramic board with a copper clad laminate, designers can expect superior power handling capabilities, making it a perfect fit for power converters, high-speed circuits, and other power-intensive applications.

The Immersion Gold Ceramic PCB Board represents the convergence of innovation and practicality. Its robust construction, coupled with its high thermal and electrical performance, positions it as a leading choice for anyone seeking a Ceramic Glass Composite PCB. Whether you're developing cutting-edge electronics or looking for reliable components for high-stress environments, this PCB provides the quality, versatility, and performance necessary to drive your projects forward.

Embrace the future of electronic component design with the Immersion Gold Ceramic PCB Board – where precision meets durability and performance. With its fine line spacing, expansive operating temperature range, customizable size, and superior surface finish, this ceramic PCB stands as a testament to excellence in the realm of electronic substrates.



Features:

  • Product Name: Ceramic PCB Board
  • Service: One-stop Service / OEM, DFM
  • Surface Finished: Immersion Gold, Nickel-Palladium GLOD
  • Min Line Width/Spacing: 0.1mm
  • Surface Technics: ENIG, Nickel-Palladium GLOD
  • Layers: 1-8 Layers
  • Material: Ceramic Board with Copper Clad Laminate
  • Type: Ceramic High Temperature PCB
  • Feature: High thermal conductivity Ceramic PCBs


Technical Parameters:

Product Attribute Specification
Product Type PCB&PCBAOEM, DFM
Dielectric Constant 6.0-10.0
Surface Technics ENIG, nickel-palladium GLOD
Surface Finished Immersion Gold, nickel-palladium GLOD
Pcb Size 22mm*19mm
Thermal Conductivity 170 W/mK
Size 2mm~200mm
Operating Temperature -50°C To 150°C
Pcb Name Immersion Gold Ceramic PCB Board
Min Line Width/Spacing 0.1mm
Technology DBC, DPC, LTCC, HTCC


Applications:

The Ceramic PCB Board, with options ranging from 1-8 layers, is an advanced type of circuit board that leverages the robustness and thermal management capabilities of ceramic materials such as Aluminum Oxide (Al2O3) and Aluminum Nitride (ALN). Ceramic Substrate PCBs are known for their exceptional thermal conductivity and electrical insulation, making them ideal for high-temperature applications and scenarios where thermal management is critical.

With a product type that encompasses both PCB and PCBA OEM, as well as DFM (Design for Manufacturability) services, these Ceramic Dielectric PCBs are designed to offer a one-stop service for clients looking to streamline their assembly process. OEM and DFM services allow for customization and optimization of the PCB to suit specific product requirements, ensuring high-quality performance and reliability.

Given their compact size of 22mm*19mm, Ceramic Hybrid PCBs are versatile enough for use in a variety of applications. These include high-power circuits, LED lighting, automotive electronics, and aerospace components, where the excellent heat dissipation properties of the ceramic material can prevent overheating and ensure the longevity of the electronic components. Furthermore, the small footprint of these PCBs allows them to be easily integrated into space-constrained designs, making them a popular choice for the latest miniature electronic devices.

Ceramic PCBs are especially useful in occasions where environmental conditions are harsh, such as in the oil and gas industry for sensors and control systems, or in military and defense applications where equipment must withstand extreme temperatures and vibrations. The robust nature of the Ceramic Substrate PCB ensures that it remains reliable under such demanding conditions.

Additionally, the medical industry benefits greatly from the use of Ceramic Dielectric PCBs in medical devices, where high precision and reliability are paramount. The non-toxicity and bio-compatibility of ceramic materials also make them suitable for sensitive applications, including implants and other in-body devices.

In the field of high-frequency electronics, Ceramic Hybrid PCBs stand out due to their low dielectric losses. This quality is essential for communication equipment, radar systems, and other RF applications where signal integrity is key. The inherent properties of the ceramic PCB allow for stable performance even at the high-frequency ranges.

In conclusion, the Ceramic PCB Board is an essential component in various high-tech industries, offering unparalleled reliability, thermal management, and performance for a wide range of applications. With one-stop service and OEM, DFM services, clients can customize these PCBs to fit their specific needs, ensuring optimal function and integration into their products.



Customization:

We offer specialized Product Customization Services for Ceramic PCB Boards , catering to high-performance applications that require advanced Ceramic Thermal Management PCB solutions. Our services include precise customization to meet your specific design requirements, with a Min Line Width/Spacing of 0.1mm for intricate circuit designs.

Our One-stop Service / OEM,DFM ensures that from design to manufacturing, you receive comprehensive support, streamlining the process and guaranteeing the highest quality products. We cater to a variety of sizes ranging from 2mm to 200mm , with our featured PCB Size being 22mm*19mm .

Whether you need a single-layer board or a complex 1-8 Layers configuration, we can accommodate your needs. Our expertise extends to Ceramic Glass Composite PCB and Ceramic Insulated Metal Substrate technologies, ensuring that your PCB can handle the thermal and electrical demands of cutting-edge electronic components.



Support and Services:

Our Ceramic PCB Board comes with comprehensive technical support and services to ensure your satisfaction and success with our product. We offer a range of services including product installation guidance, troubleshooting assistance, and technical advice to optimize your use of our Ceramic PCB Board.

For customers requiring additional support, we provide detailed documentation and FAQs that cover common issues and best practices. Our dedicated support team is available to assist with any product-related queries, and we endeavor to provide timely and effective solutions to any challenges you may encounter.

Our commitment to quality means we also offer a warranty service for the Ceramic PCB Board, covering any manufacturing defects. Please refer to the warranty documentation for specific terms and conditions.

We are dedicated to continual improvement and welcome customer feedback on our products and support services. Your input helps us to enhance our offerings and better serve your needs.

Please note that our technical support and services do not include physical repair or replacement of components not covered under warranty. We recommend handling the board in accordance with our guidelines to ensure longevity and reliability.
