High Speed PCB Board with 0.15mm Inner Layer Spacing and 8 Layer Multilayer Design

Product Description:

Experience exceptional performance with our HDI Printed Circuit Boards featuring advanced technology and high-quality materials. This High Speed PCB Board is designed to meet the demands of modern applications, providing reliability and efficiency for your projects.

Our HDI PCB Board boasts a 10-layer design, offering enhanced functionality and versatility for complex circuitry needs. With a white silk finish, this board not only performs well but also looks sleek and professional in any setup.

When it comes to precision, our HDI Printed Circuit Boards excel with an inner layer spacing of 0.15mm, ensuring optimal signal integrity and minimizing interference. This feature is crucial for maintaining signal quality in high-speed applications such as HD SDI converters.

Additionally, our HDI PCB Board is equipped with the smallest hole size of 0.1mm, allowing for intricate designs and compact layouts without compromising on performance. This level of detail is essential for achieving efficient and reliable connections in your electronic projects.

For superior material quality, our HDI Printed Circuit Boards feature glass epoxy made of RO4350B from Rogers Corp. This advanced material offers high thermal performance with a Tg of 280℃, ensuring stability and durability even under demanding conditions. With an Er value of less than 3.48, this glass epoxy material provides excellent signal transmission efficiency, making it ideal for high-frequency applications.

Whether you are working on high-speed data processing, telecommunications equipment, or HD SDI converters, our HDI PCB Board is the perfect choice to meet your performance requirements. Trust in our reliable and high-quality product to deliver exceptional results for your projects.

Features:

• Product Name: HDI PCB Board
• Smallest Hole Size: 0.1mm
• PCB Thickness: 1.6mm
• PCB Type: 8 Layer Multilayer PCB Board
• Min Via: 0.1mm
• Surface: Immersion

Technical Parameters:

Applications:

When it comes to HDI PCB Manufacturing, the HDI PCB Board with S1000-2M base material stands out as a top choice for various product application occasions and scenarios. With features like blind and buried vias, minimum trace of 3/3 mil, white silk, and a thickness range of 0.4-3.2mm, this high-speed PCB board is ideal for a wide range of applications.

One key application scenario for the HDI PCB Board is in the production of high-performance computing devices. The advanced technology of the S1000-2M base material combined with blind and buried vias allows for complex layouts and high-density interconnections, making it perfect for DDR4 PCB designs. The minimum trace of 3/3 mil ensures precise signal transmission, crucial for high-speed data processing.

Another important application occasion for this PCB board is in the telecommunications industry. The white silk layer provides a clean and professional appearance, making it suitable for telecommunications equipment where aesthetics are important. The ability to accommodate blind and buried vias enhances signal integrity, making the HDI PCB Board a reliable choice for communication devices that require high data transmission rates.

Furthermore, the HDI PCB Board is well-suited for use in consumer electronics, such as smartphones and tablets. The thin profile and flexibility of the board, with a thickness range of 0.4-3.2mm, make it easy to integrate into compact electronic devices without sacrificing performance. The high-density interconnections provided by blind and buried vias ensure efficient signal routing, enhancing the overall functionality of the electronic products.

In conclusion, the HDI PCB Board is a versatile solution for a variety of product application occasions and scenarios, particularly in the realms of high-speed PCB manufacturing, DDR4 PCB production, and advanced telecommunications and consumer electronics. Its unique combination of features and capabilities make it a top choice for demanding applications that require reliable performance and precision engineering.

Customization:

Product Customization Services for the HDI PCB Board:

- Silk: White

- Glass Epoxy: RO4350B Tg280℃, Er<3.48, Rogers Corp

- PCB Thickness: 1.6mm

- Inner Layer Spacing: 0.15mm

- Testing: 100%E-Testing, X-RAY

Keywords: DDR4 PCB, High Speed PCB, HDI PCB
