Efficiently-designed HDI Printed Circuit Boards with Immersion Gold Process and P1.5 Spacing

Product Description:

The HDI PCB Board is a cutting-edge product designed for high-density interconnection applications, offering unmatched performance and reliability. With a minimum BGA pitch of 0.3mm, this board is ideal for compact electronic devices that require intricate circuitry and tight component spacing.

One of the key features of the HDI PCB Board is its superior surface finishing options, including gold plating and HASL lead-free coating. These finishes not only enhance the board's durability and corrosion resistance but also ensure optimal electrical performance.

When it comes to quality assurance, this product stands out with its 100% electrical test prior to shipment. This rigorous testing process guarantees that each board meets the highest standards of functionality and reliability, providing peace of mind to users and manufacturers alike.

Another notable attribute of the HDI PCB Board is its exceptional tolerance for misalignment of layers, with a margin of only +/- 0.06. This precision engineering ensures that all components align seamlessly, minimizing the risk of signal interference and improving overall system performance.

Whether you are working on a project that requires high-density interconnects or developing a compact electronic device that demands a reliable and efficient PCB solution, the HDI PCB Board is the perfect choice. Its advanced design, top-notch surface finishing, and stringent quality control make it a standout option for applications such as HD SDI converters, high-density model boards, and other demanding electronic projects.

Features:

• Product Name: HDI PCB Board
• Blind Vias: Yes
• Impedance Control: +/-10%
• Misalignment Of Layers: +/- 0.06
• Aspect Ratio: 10:1
• Key Words: High Density Interconnector, DDR4 PCB, High Density PCB, High Speed PCB

Technical Parameters:

Applications:

The HDI PCB Board is a versatile product that can be applied in a variety of occasions and scenarios due to its advanced features and specifications.

One of the key features of the HDI PCB Board is its ENIG surface finishing, which provides excellent conductivity and corrosion resistance. This makes it ideal for high-speed PCB applications, such as in data centers, networking equipment, and telecommunications systems.

With surface finishing options including Gold Plating and HASL Lead Free, the HDI PCB Board offers flexibility in meeting different project requirements. The Gold Plating ensures superior signal integrity and reliability, while the HASL Lead Free option is environmentally friendly and cost-effective.

Designed for high-density interconnector applications, the HDI PCB Board is well-suited for scenarios that demand compact and reliable circuit connections. Its minimum BGA pitch of 0.3mm allows for intricate designs and space-saving layouts, making it a preferred choice for DDR4 PCB implementations.

The aspect ratio of 10:1 further enhances the HDI PCB Board's capabilities, enabling it to support complex circuit designs with stacked vias and microvias. This makes it suitable for use in advanced electronics, such as smartphones, tablets, and IoT devices.

In summary, the HDI PCB Board is a high-performance solution that excels in high-speed PCB applications, offering the reliability and efficiency required for modern electronic systems. Whether it's for DDR4 PCB designs or other advanced projects, the HDI PCB Board proves to be a versatile and dependable choice.

Customization:

Product Customization Services for HDI PCB Board:

Process: Immersion Gold/silver

Min. Bga Pitch: 0.3mm

Surface Finishing: Gold Plating, HASL Lead Free

Test: 100% Electrical Test Prior Shipment
