Ceramic Substrate Ceramic Insulated Metal Substrate Featuring 1.6 MM PCB Thickness Ideal for Medical Electronic Devices

ceramic PCB board for medical devices

1.6mm ceramic insulated metal substrate

ceramic substrate PCB with high insulation

Request A Quote

Ceramic Substrate Ceramic Insulated Metal Substrate Featuring 1.6 MM PCB Thickness Ideal for Medical Electronic Devices

Product Details

Substratetype:

Ceramic

Surfacefinish:

ENIG, HASL, Gold Plating

Application Segment:

Auto,Industrial,Medical,DataCom、Comsumer

Dielectricconstant:

7-9

Thickness:

0.1mm - 3.0mm

Copperthickness:

18µm - 105µm

Application:

High Power Electronics, LED Lighting, RF Modules

Testing Service:

100% E-Testing

Highlight:

ceramic PCB board for medical devices

1.6mm ceramic insulated metal substrate

ceramic substrate PCB with high insulation

Payment & Shipping Terms

Medical Ceramic PCB Board Incorporating Ceramic Substrate and HASL Surface Finish Providing Excellent Thermal Management

Get Best Price

RF Modules Ceramic PCB Board UL Certified Featuring Ceramic Thickfilm PCB Designed for Complex Electronic Circuit Integration

Get Best Price

Ceramic Substrate Type Ceramic PCB Board UL Certified Including 100 Percent E Testing Service Ensuring and Durability in Electronics

Get Best Price

Thickness 0.1mm to 3.0mm Ceramic Copper Clad PCB Featuring Size Range 2mm to 200mm Perfect for High Reliability Circuits

Get Best Price

+001-512-7443871

sales@ltcircuit.com

Contact Now

Product Description

Ceramic Substrate Ceramic Insulated Metal Substrate

Featuring 1.6 MM PCB thickness, this advanced ceramic PCB board is ideally suited for medical electronic devices and other demanding applications requiring exceptional thermal management and electrical performance.

Product Overview

The Ceramic PCB Board is a highly reliable solution designed for applications requiring superior thermal conductivity and electrical performance. As part of the Ceramic Thickfilm PCB category, it offers enhanced thermal management and mechanical stability compared to traditional FR4 and other organic substrates.

This versatile product supports configurations ranging from 1 to 4 layers, accommodating various circuit complexities. Available in sizes from 2mm to 200mm, it suits everything from compact sensor modules to larger power electronics assemblies.

Copper thickness options from 18µm to 105µm provide flexibility in current carrying capacity and thermal dissipation. Surface finish choices include ENIG (Electroless Nickel Immersion Gold), HASL (Hot Air Solder Leveling), and Gold Plating for optimal protection and solderability.

Key Features

Product Name: Ceramic PCB Board (Item No: R0028)
Layer Count: 1-4 Layers
Substrate Type: Ceramic
Copper Thickness: 18µm - 105µm
Applications: High Power Electronics, LED Lighting, RF Modules
Ceramic High Temperature PCB for excellent thermal performance
Manufactured using Al2O3 Ceramic PCBs ensuring durability and reliability
Incorporates Ceramic Insulated Metal Substrate technology for enhanced insulation and heat dissipation

Technical Specifications

Parameter	Specification
Application	High Power Electronics, LED Lighting, RF Modules
Dielectric Constant	7-9
Item No	R0028
Substrate Type	Ceramic
Layer Count	1-4 Layers
Application Segment	Auto, Industrial, Medical, DataCom, Consumer
Surface Finish	ENIG, HASL, Gold Plating
Testing Service	100% E-Testing
PCB Thickness	1.6 MM
Size	2mm ~ 200mm

Applications

The Ceramic PCB Board R0028 is specifically designed for demanding applications in high power electronics, LED lighting, and RF modules. With a dielectric constant of 7-9 and superior thermal conductivity, it ensures reliable performance in high-frequency and high-power environments.

In high power electronics, the board's exceptional heat dissipation prevents overheating and extends component lifespan. LED lighting systems benefit from optimal thermal management, enhancing brightness and energy efficiency. RF modules require stable dielectric properties and minimal signal loss, making this ceramic PCB an ideal choice.

Each board undergoes rigorous 100% E-Testing to guarantee flawless performance under operational conditions, providing manufacturers and engineers with reliable solutions for sophisticated electronic devices.

Customization Services

Our ceramic PCB customization services meet specific requirements for high power electronics, LED lighting, and RF modules. We offer ALN Ceramic PCBs with thickness ranging from 0.1mm to 3.0mm and support layer counts from 1 to 4 layers.

With a standard PCB thickness of 1.6mm, our Ceramic Insulated Metal Substrate solutions provide excellent thermal conductivity and electrical insulation. Every customized ceramic PCB undergoes 100% E-Testing to ensure it meets the highest industry standards.

Technical Support & Services

To ensure optimal performance and longevity of your ceramic PCB, please follow these guidelines:

Handling: Handle with care to avoid mechanical stress or cracking. Use anti-static measures to prevent ESD damage.

Installation: Use proper mounting techniques to avoid warping. Employ compatible soldering materials and processes recommended for ceramic substrates.

Troubleshooting: Verify correct installation and secure connections. Inspect for visible damage or contamination affecting functionality.

Maintenance: Keep the board clean and free from dust, oils, or contaminants using appropriate cleaning agents.

Warranty: Our ceramic PCB boards come with quality assurance warranty. For technical assistance or product specifications, consult our technical support team or product documentation.
