±10% Thickness White Silkscreen HDI PCB Board for Density Interconnect Applications

Product Description:

Introducing our cutting-edge HDI Printed Circuit Boards, designed to meet the demands of high-speed applications with precision and reliability. Our HDI PCB Board with Immersion Silver finish is engineered using top-quality Glass Epoxy material, specifically RO4350B from Rogers Corp., with a high Tg of 280℃ and a low dielectric constant of less than 3.48.

One of the key highlights of our HDI PCB Board is its exceptional Min. Solder Mask Bridge of just 0.075mm, ensuring optimal performance and preventing any soldering issues. This feature is crucial for high-speed designs where accuracy and consistency are paramount.

When it comes to copper thickness, our HDI PCB Board offers a versatile range from 0.5oz to 6oz, providing flexibility for various applications and requirements. The Finished Copper Thickness of 1oz further enhances the durability and conductivity of the board, making it suitable for a wide range of high-speed PCB Board applications.

Whether you are working on telecommunications, automotive, aerospace, or any other industry that demands high-speed performance, our HDI PCB Board with Immersion Silver finish is the ideal solution. Its superior quality, precise design, and reliable performance make it a top choice for professionals seeking advanced PCB solutions.

Experience the difference with our state-of-the-art HDI Printed Circuit Boards, meticulously crafted to deliver exceptional results and meet the stringent requirements of high-speed applications. Trust in our expertise and quality assurance to take your projects to the next level with our high-speed PCB Board solutions.

Features:

• Product Name: HDI PCB Board
• Surface Mount Technology: Available
• Thickness: 1.6mm, ±10%
• Glass Epoxy: RO4350B Tg280℃, Er<3.48, Rogers Corp.
• Mini Holes: 0.1mm
• Vias Aspect Ratio: 16:1

Technical Parameters:

Applications:

When it comes to High Density Interconnector (HDI) PCB boards, the product application occasions and scenarios are diverse and cater to a wide range of industries and technological needs. The unique attributes of HDI PCB boards, such as surface finish options like HASL, ENIG, OSP, Immersion Silver, Immersion Tin, etc., make them suitable for various specialized applications.

HDI PCB boards with a vias aspect ratio of 16:1 are specifically designed for applications where space is limited, and high interconnect density is required. The ability to accommodate high-density interconnects makes HDI PCB boards ideal for use in compact electronic devices such as smartphones, tablets, wearables, and other portable gadgets where miniaturization is key.

With a copper thickness ranging from 0.5oz to 6oz, HDI PCB boards offer flexibility in design and performance, making them suitable for applications that require varying levels of conductivity and signal integrity. The VIP process, a key feature of HDI PCB manufacturing, further enhances the reliability and performance of the boards, making them ideal for critical applications in industries such as aerospace, medical devices, automotive, and telecommunications.

The high-density interconnect capabilities of HDI PCB boards make them well-suited for applications that demand complex and compact designs, such as high-speed data processing, advanced computing systems, IoT devices, and high-performance computing. The use of HDI PCB boards in these scenarios ensures improved signal integrity, reduced signal loss, and enhanced overall performance.

In conclusion, HDI PCB manufacturing plays a crucial role in meeting the demands of modern electronic devices and technologies. With their high-density interconnector capabilities, surface finish options, vias aspect ratio, copper thickness variations, and VIP process, HDI PCB boards are versatile solutions for a wide range of applications across industries that require high-performance, reliability, and miniaturization.

Customization:

Product Customization Services for the High Density Model Board (HDI PCB Board) include:

Finished Copper Thickness: 1oz

Silkscreen: White, Black, Yellow, Etc.

PCB Assembly Process: SMT THT DIP SMT PCB Assembly

Vias Aspect Ratio: 16:1

Surface Mount Technology: Available

Explore customization options for your High Speed PCB Board, HD SDI Converter with our diverse range of services.

Support and Services:

Our Product Technical Support and Services for the HDI PCB Board include:

- Expert assistance with product installation and setup

- Troubleshooting guidance for any technical issues

- Firmware updates and software upgrades

- Product training and tutorials

- Warranty support and repair services
