Standard Technology Dual Layer PCB 1.6mm Board Thickness for Superior Performance

Product Description:

The Double Sided PCB, also known as Bi-Layer PCB or Dual Layer PCB, is a versatile and reliable circuit board that is ideal for a wide range of electronic applications. With a surface finishing option of HASL, OSP, ENIG, Immersion Gold, or lead-free, this 1.5m double-sided PCB offers excellent quality and performance.

One of the key features of this Double Sided PCB is its Special Tech of Impedance Control with a tolerance of ±10%. This ensures that the signals traveling through the board are stable and consistent, making it suitable for high-frequency applications where signal integrity is crucial.

Another Special Technology offered with this Double Sided PCB is Standard, which means it meets industry standards for quality and performance. This guarantees that the PCB is manufactured using the latest technology and processes to deliver reliable and efficient results.

In addition to the advanced technical features, this Double Sided PCB also comes with the option of Other Services such as PCB Design and PCB Assembly. This provides customers with a one-stop solution for their PCB needs, from design to assembly, saving time and ensuring a seamless production process.

The surface of this Double Sided PCB is OSP, which stands for Organic Solderability Preservatives. OSP is a cost-effective surface finish that offers excellent solderability and flatness, making it suitable for various soldering applications.

Features:

• Product Name: Double Sided PCB
• Special Requirement: Halogen Free/impedance Control
• Surface: OSP
• Special Tech: Impedance Control ;±10%
• Min. Hole To Copper: 0.2mm
• Type: Offline

Technical Parameters:

Applications:

Double Sided PCBs with OSP surface are versatile and widely used in various product applications and scenarios. The Halogen Free and impedance control attributes make them ideal for sensitive electronic devices where these requirements are crucial.

One of the key product attributes is the number of layers, with these Double Sided PCBs offering 2 layers. This design is perfect for applications that require a balance of complexity and simplicity in the circuitry.

The use of 1oz copper in these PCBs ensures good conductivity and reliability in different electronic applications. The copper thickness is suitable for a range of devices, making these PCBs suitable for consumer electronics, industrial equipment, and more.

With a minimum hole to copper distance of 0.2mm, these Double Sided PCBs are suitable for intricate designs that require precision in component placement and routing.

Product Application Occasions and Scenarios for these Double Sided PCBs include but are not limited to:

- Overlength PCBs: These PCBs are suitable for applications that require longer and more complex circuit designs without compromising on performance.

- Double-Plated PCB: The dual layer design of these PCBs allows for more components to be integrated, making them suitable for devices that require higher circuit density.

- Dual Layer PCB: The 2-layer design offers flexibility in routing and component placement, making these PCBs suitable for a wide range of electronic devices.

Overall, the Double Sided PCBs with OSP surface, Halogen Free/impedance control, 2 layers, 1oz copper, and 0.2mm minimum hole to copper distance are a reliable choice for various electronic applications that require precision, reliability, and performance.

Customization:

Product Customization Services for the Extra long double-sided PCB, Bi-Layer PCB, and Dual-Sided Printed Wiring Board:

Type: Offline

Materials: FR4

Number Of Layers: 2

Solder Resist Color: Green

Min. Hole To Copper: 0.2mm

Support and Services:

Our Product Technical Support and Services for the Double Sided PCB include:

- Assistance with product installation and setup

- Troubleshooting guidance for any technical issues

- Product maintenance tips and best practices

- Training resources for using the Double Sided PCB efficiently

- Warranty support and repair services for any defects
