We use only the best quality raw material - FR4 IT180 - to ensure that our High Density PCB Board is durable, reliable and can withstand high frequency and high-speed signals. Our High Density PCB Board is designed with Half Hole and 0.25mm BGA technology to ensure a perfect fit for all electronic components.
Our High Density PCB Board is rigorously tested before it is delivered to our customers. We use 100% E-Testing and X-Ray technology to ensure that our High Density PCB Board meets the highest industry standards.
We understand that every customer has unique requirements, which is why we offer customized solutions based on your specific needs. Our High Density PCB Board can be designed with a Lamp Socket to meet your specific requirements.
Our High Density PCB Board is ideal for high-speed electronic applications, such as high-speed communication devices, data storage devices, and high-end computing systems. We are confident that our High Density PCB Board will meet your requirements and exceed your expectations.
This High Density Model Board is perfect for use as an HD SDI Converter, with its high layer count and impedance control capabilities.
| Technical Parameters | Values |
|---|---|
| PCB Name | 4L 1+N+1 HDI Boards |
| Layer Count | 4-20 Layers |
| Board Thickness | 0.2mm-6.00 Mm(8mil-126mil) |
| Board Layer | 6-32L |
| Impedance Control | Yes |
| Aspect Ratio | 10:1 |
| Special Requirements | Lamp Socket |
| Min Trace | 3/3Mil |
| Minimum Hole Size | 0.15mm |
| Thickness | 0.4-3.2mm |
HDI PCB Manufacturing: The HDI PCB Board is an excellent choice for manufacturing high-density interconnects. With its 0.1mm laser drill hole size and 10:1 aspect ratio, it can provide high-density interconnects with excellent performance and reliability. Additionally, the board's minimum hole size of 0.15mm ensures that even the most intricate designs can be achieved.
High Speed PCB: The HDI PCB Board is also an ideal choice for high-speed PCBs. With its 3/3mil minimum trace width and spacing, it can provide excellent signal integrity and reduce signal loss. This makes it an excellent choice for applications that require high-speed data transfer, such as telecommunications, computing, and networking.
Small Form Factor PCBs: The HDI PCB Board is an ideal choice for small form factor PCBs. With its high-density interconnects, it can provide excellent performance and reliability in a compact size. This makes it an excellent choice for applications that require a small form factor, such as wearable technology, IoT devices, and medical devices.
Consumer Electronics: The HDI PCB Board is an excellent choice for consumer electronics. With its high-performance and reliability, it can provide excellent performance in a wide range of consumer electronics products, such as smartphones, tablets, and gaming consoles.
Automotive Electronics: The HDI PCB Board is also an ideal choice for automotive electronics. With its high-density interconnects and excellent performance, it can provide reliability and durability in harsh automotive environments. This makes it an excellent choice for automotive applications, such as engine control units, infotainment systems, and safety systems.
Aerospace and Defense: The HDI PCB Board is also an excellent choice for aerospace and defense applications. With its high-performance and reliability, it can provide excellent performance in a wide range of aerospace and defense applications, such as satellites, avionics systems, and military equipment.
Overall, the HDI PCB Board is an excellent choice for a wide range of applications. With its high-density interconnects, high-speed PCB capabilities, and small form factor capabilities, it can provide excellent performance and reliability in a wide range of industries.
Our High Speed PCB Board product, 4L 1+N+1 HDI Boards, is customizable to meet your specific needs. If you require a Lamp Socket, we can accommodate that special requirement. Our HDI PCB boards can have a board thickness ranging from 0.2mm-6.00mm (8mil-126mil), and we can also include Half Holes and 0.25mm BGAs upon special request. With layer counts ranging from 4-20 Layers, our HDI Printed Circuit Boards are ideal for high speed applications that require advanced technology. Trust us to deliver a customizable solution that meets your unique needs.
