Product Description

Product Description:

The IMS PCB, or Insulated Metal Substrate Printed Circuit Board, is a high-performance product designed to meet the demanding requirements of various electronics applications. With an emphasis on durability, thermal management, and reliability, IMS PCB from Ventec metal PCB is an ideal solution for projects that require efficient heat dissipation and robust physical properties.

One of the critical features of the IMS PCB product is its versatility in thermal conductivity options. Customers can choose from a range of thermal conductivity values, including 0.5, 1, 2, 3, 5, and 8 W/mK, with specialized options such as 1.0w and >=1.0W/mK. This range allows designers to select the most appropriate thermal performance for their specific application, ensuring that electronic components operate within safe temperature limits and maintain optimal performance throughout their lifespan.

In addition to its thermal capabilities, the IMS PCB from Ventec PCB is engineered to be electrically robust, boasting a withstand voltage of greater than 3KV. This high dielectric strength makes it suitable for high-voltage applications and provides an extra layer of safety and reliability, which is critical in sensitive electronic equipment and devices where electrical insulation is of utmost importance.

The surface finish of a printed circuit board is crucial for ensuring good solderability and protecting the underlying copper tracks from oxidation. Our IMS PCB products are available with a variety of surface finishes to meet the specific needs of our customers. These include HASL (Hot Air Solder Leveling), ENIG (Electroless Nickel Immersion Gold), OSP (Organic Solderability Preservatives), and Immersion Silver. Each of these finishes offers benefits such as long shelf life, excellent solderability, and compliance with RoHS regulations, allowing for flexibility in assembly processes and end-use environments.

Aesthetically, the IMS PCB can be customized with a silkscreen in white, black, or yellow. The silkscreen layer is not only a means for adding a visual touch but also serves as a guide for component placement and provides valuable information to assembly and service technicians. The use of high-contrast colors like white, black, and yellow ensures readability and professionalism in the final product presentation.

Quality and environmental responsibility are foundational to the manufacturing process of Ventec metal PCB products. To this end, the IMS PCB is produced under stringent quality control measures compliant with ISO 9001:2015, ensuring consistent product quality and customer satisfaction. Additionally, environmental management systems are certified to ISO 14001:2015, demonstrating a commitment to sustainable manufacturing practices. Medical device manufacturers can rely on the IMS PCB as well, thanks to the ISO 13485:2016 certification, which attests to the rigorous standards in place for medical-grade PCB production.

The combination of advanced thermal management, high electrical insulation, versatile surface finishes, and customizable aesthetics makes the IMS PCB from Ventec metal pcb an outstanding choice for a wide array of applications. Whether it is used in LED lighting, power equipment, automotive systems, or medical devices, the IMS PCB stands up to the challenge, providing designers and engineers with the confidence that their products will perform reliably even in the most demanding conditions.

In summary, the IMS PCB represents the pinnacle of Ventec PCB technology, offering a blend of performance, quality, and environmental consideration. With its broad range of thermal conductivities, high withstand voltage, variety of surface finishes, choice of silkscreen colors, and adherence to international standards, it is clear why the IMS PCB is the go-to option for industry professionals seeking the best in printed circuit board technology.



Features:

  • Product Name: IMS PCB
  • Type: Insulation Sheet, PCB Base Board
  • Materials: Ventec, Polytronics, Bergquist
  • PCB Thickness: 0.6-6.0MM
  • ISO Certification: ISO 9001:2015, ISO 14001:2015, ISO 13485:2016
  • Service: PCB Fabrication
  • Feature: High thermal conductivity IMS PCB
  • Feature: High thermal conductivity metal pcb


Technical Parameters:

Parameter Detail
PCB thickness 0.6-6.0MM
Silkscreen White, Black, Yellow
Solder Mask Color Clients Required
Type Insulation Sheet, PCB Base Board
Surface Finish HASL, ENIG, OSP, Immersion Silver
Sample Available
ISO Certification ISO 9001:2015, ISO 14001:2015, ISO 13485:2016
Min. Line Width/Spacing 0.075/0.075mm
Withstand voltage >3KV
Materials Ventec, Polytronics, Bergquist


Applications:

The High thermal conductivity IMS (Insulated Metal Substrate) PCB is a pivotal component in applications where effective heat dissipation is crucial. Designed to cater to a wide range of thermal management requirements, this type of PCB boasts a thickness ranging from 0.6 to 6.0MM, which allows for flexible design considerations in various electronic assemblies. Manufactured using premium materials from industry-renowned suppliers such as Ventec, Polytronics, and Bergquist, the High thermal conductivity IMS PCB guarantees superior performance and reliability.

Samples of the High thermal conductivity IMS PCBs are available for testing and validation to ensure they meet the specific needs of your projects. The ability to withstand voltages greater than 3KV makes these PCBs exceptionally suitable for high-power and high-voltage applications. Clients can also specify the solder mask color, enabling customization to align with aesthetic design requirements or coding for easy identification.

One of the prime applications for the High thermal conductivity IMS PCB is in LED lighting systems. The ventec metal pcb is particularly effective in these scenarios, as it can manage the heat generated by high-intensity LEDs, maintaining the overall performance and extending the lifespan of the lighting systems. This is particularly beneficial in automotive lighting, street lights, and industrial high bay lights where reliability and longevity are paramount.

Additionally, the High thermal conductivity IMS PCB is ideal for use in power converters and inverters. These applications often deal with significant electrical power levels that can generate substantial heat. The robust thermal management capabilities of these PCBs ensure that the devices remain operational and safe, even under intense operating conditions.

Other scenarios that benefit from the exceptional qualities of the High thermal conductivity IMS PCB include motor controllers, audio amplifiers, and solar power inverters. In each of these cases, the ability of the IMS PCB to effectively dissipate heat contributes to enhanced performance, reduced risk of overheating, and improved overall device efficiency. The availability of customization options further ensures that the IMS PCB can be tailored to fit a wide array of applications, making it a versatile solution for numerous industries looking to leverage the benefits of advanced thermal management.



Customization:

Silkscreen Options: Customize your PTTC metal PCB with a choice of White, Black, or Yellow silkscreen to match your design requirements and aesthetic preferences.

Sample Availability: We understand the importance of quality and testing. Samples are available to evaluate our IMS PCB product before committing to a full order.

Number Of Layers: Our IMS PCB is offered as a 1 Layer Printed Circuit Board, ideal for a variety of applications that require a single conductive layer.

Material Selection: Choose from top-grade materials for your PTTC metal pcb needs, including Ventec, Polytronics, and Bergquist, ensuring your PCB meets the highest standards of quality and performance.

ISO Certified: Our commitment to excellence is demonstrated by our ISO certifications, including ISO 9001:2015, ISO 14001:2015, and ISO 13485:2016, guaranteeing that your ventec pcb is manufactured to the highest international standards.



Support and Services:

Welcome to the Product Technical Support and Services for the IMS PCB product. Our dedicated team is here to assist you with any technical issues or questions you may have regarding your IMS PCB (Insulated Metal Substrate Printed Circuit Board). We offer a comprehensive range of services to ensure your product functions optimally.

Technical Support Services Include:

  • Troubleshooting assistance for any operational issues
  • Guidance on best practices for PCB handling and maintenance
  • Advice on thermal management and design optimization
  • Assistance with electrical performance queries
  • Help with component compatibility and selection
  • Support for firmware updates and software configuration

Additional Services:

  • PCB layout and design consultation
  • Thermal simulation and analysis
  • Prototype testing and validation
  • Product customization support
  • End-of-life product management and recycling information

Our team is committed to providing you with the highest quality support for your IMS PCB product. Please refer to the product documentation and FAQs for immediate assistance, or contact our technical support team for further help.
